Overview

VGStudio is a software platform developed by Volume Graphics for the comprehensive analysis, visualization, and reporting of industrial computed tomography (CT) data. It enables users to extract high-quality insights from 3D scan data, making it suitable for various applications such as defect detection, assembly analysis, and process optimization in manufacturing. The software provides advanced tools for visualizing and manipulating 3D data, offering a high level of precision and reliability.

Features and Capabilities

• 3D Visualization and Analysis: Offers advanced tools for visualizing and analyzing CT scan data in three dimensions, facilitating detailed inspection of complex structures.
• Defect Detection: Equipped with algorithms for identifying and analyzing defects within scanned objects, aiding in quality control processes.
• Wall Thickness Analysis: Provides tools to measure and evaluate wall thicknesses in scanned objects, essential for assessing structural integrity.
• Coordinate Measurement: Enables precise measurement of coordinates within the scanned data, supporting dimensional analysis and quality assurance.
• Actual/Nominal Comparison: Allows for the comparison between actual scanned data and nominal CAD models, facilitating tolerance analysis and deviation detection.
• CT Reconstruction: Includes modules for reconstructing 3D volume data from CT images, enabling comprehensive analysis of internal structures.
• Automated Workflows: Supports the automation of analysis processes, enhancing efficiency and consistency in data evaluation.
• Integration with CAD and Simulation Software: Offers compatibility with various CAD and simulation tools, streamlining the workflow from design to analysis.
• Comprehensive Reporting Tools: Provides robust reporting capabilities for documenting analysis results, essential for quality assurance and compliance.
• Multi-Material and Multi-Phase Scan Support: Capable of handling scans involving multiple materials or phases, broadening its application range.
• High Scalability: Designed to efficiently process large datasets, accommodating complex and detailed scans.
• Cross-Platform Compatibility: Available for both Windows and Linux operating systems, offering flexibility in deployment.
• Real-Time Data Processing: Enables real-time processing of scan data, facilitating immediate analysis and decision-making.
