SkyCiv Retaining Wall Design Software is a cloud-based tool for designing concrete and block retaining walls, including gravity and cantilever types. It performs essential stability checks such as overturning, sliding, and bearing capacity, and allows engineers to model various wall components and soil conditions. The software supports detailed design calculations and generates professional PDF reports with step-by-step references. Accessible directly from any browser, SkyCiv Retaining Wall Design integrates with other SkyCiv modules and offers real-time collaboration, making it ideal for structural engineers working on residential, industrial, and institutional projects.

Features

• Wall Types Supported: Cantilever and gravity retaining walls.
• Stability Checks:
  • Overturning calculations to prevent tipping.
  • Sliding calculations to resist lateral earth pressure.
  • Bearing calculations to ensure ground support.
• Soil Modeling:
  • Passive, active, and substructure soils.
  • Inclined and multi-layered soil configurations.
• Structural Components:
  • Stem (including tapered), base input, and keys.
• Loading Options:
  • Line, patch, and uniform loading.
• Calculation Outputs:
  • Clear capacity and factor of safety results.
  • Detailed PDF reports with calculation steps and code references.
• Cloud-Based Access: No installations—accessible from any browser.
• Modeling Tools: Pen tool, bulk editing, camera roll, and more.
• Collaboration Tools: Real-time file sharing and permission control.
• Unified SkyCiv Access: One account for all SkyCiv software.
• Software Integrations: Revit, Excel, Google Drive, Grasshopper, Slack, Microsoft Teams.
• API Access: Automate workflows like solar frame design.
• Flexible Pricing: No lock-in contracts; tailored plans available.

Benefits

• Efficiency: Quickly design retaining walls with integrated modeling and analysis.
• Transparency: Step-by-step reports eliminate black-box concerns.
• Accessibility: Use from anywhere with just a browser.
• Collaboration: Share models and get support in real time.
• Scalability: Suitable for projects of all sizes.
• Support: Responsive technical assistance from SkyCiv engineers.
• Automation: API enables integration into custom workflows.
