Overview

RADAN Essential Combi is a versatile, machine-independent CAM solution developed by Hexagon's RADAN to efficiently program punch, profile, and combination machines. Designed to integrate seamlessly with existing CAD systems, it streamlines the entire programming process—from tooling and nesting to sequencing and code generation—ensuring optimal machine performance and reduced lead times. By consolidating process-critical data within a Manufacturing Database (MDB), it maintains accuracy and consistency across operations, enhancing production efficiency and supporting advanced machine features.

Features and Capabilities

• Data Input:
  • Drag-and-drop functionality for easy data input.
  • Batch processing of DXF/DWG files, including healing capabilities.
• Tooling and Sequencing:
  • Automatic tooling and sequencing to streamline operations.
  • Support for machines' advanced features to enhance performance.
• Nesting:
  • Single-part true-shaped nesting for material optimization.
  • Project nesting with user-definable reports for comprehensive insights.
• Cutting Optimization:
  • Automatic common line cutting to reduce material waste.
  • Automatic remnants, sheet scrapping, and off-cuts management.
• Interface and Usability:
  • Simple, intuitive interface with clear, straightforward icons.
  • Graphical program verification for error reduction.
• Part Handling:
  • Automatic part removal to improve workflow efficiency.
• Efficiency Enhancements:
  • Improved machine and tooling efficiency for better resource utilization.
  • Reduced lead times and increased production throughput.
