The MapleSim Battery Library is an add-on for MapleSim that provides advanced, physics-based tools for modeling, simulating, and analyzing battery cells and battery packs. It supports both electrochemical and equivalent-circuit models, allowing users to accurately represent battery behavior under various conditions. The library includes customizable cell chemistries, thermal modeling, degradation effects, and parameter estimation tools, making it suitable for applications ranging from electric vehicles to energy storage systems. Integration with MapleSim’s multidomain environment enables system-level studies of battery performance, thermal effects, and aging, supporting both design and hardware-in-the-loop (HIL) testing workflows.

Key Features

Physics-based Battery Modeling Short description: Enables accurate simulation of battery cells and packs using electrochemical and equivalent-circuit models.

• Supports major chemistries (Li-Ion, NiMH, etc.)
• Models electrochemical reactions and dynamic effects

Thermal and Degradation Effects Short description: Captures heat generation, thermal transfer, and battery aging within simulations.

• Isothermal, convection, and external heat port options
• Includes battery degradation and state-of-health (SOH) modeling

Customizable Cell and Pack Configurations Short description: Allows flexible creation of custom battery stacks and packs.

• Configure series/parallel cell arrangements
• Select electrode materials and thermal properties

Parameter Estimation Tools Short description: Provides tools to calibrate models from experimental data.

• Uses global optimization algorithms for parameter fitting
• Supports integration of test data for enhanced accuracy

System-level Integration Short description: Integrates with MapleSim’s multidomain modeling environment.

• Combine with electrical, mechanical, and thermal systems
• Export models for real-time and HIL testing (e.g., FMI standard)

Benefits

Enhanced Design Accuracy Short description: Improves battery system design through detailed and customizable simulation.

• Predicts performance under diverse operating conditions
• Reduces reliance on physical prototypes

Accelerated Development and Testing Short description: Streamlines model-based development and validation.

• Enables hardware-in-the-loop (HIL) and real-time testing
• Supports rapid parameterization and calibration

Comprehensive System Analysis Short description: Facilitates holistic understanding of battery behavior in complex systems.

• Simulates interactions with other system components
• Analyzes thermal, electrical, and degradation effects together
