Cortona2D Editor Pro

Cortona2D Editor Pro is a powerful vector graphics editor designed for creating, modifying, and rendering layered 2D graphic primitives. It supports a wide range of formats and standards, including CGM Version 4, WebCGM 2.0/2.1, ATA GREXCHANGE, and S1000D. The tool is ideal for authors and illustrators working with legacy graphics or content generated via Cortona3D RapidAuthor and RapidAuthor for Teamcenter.

Features

• Create and edit 2D vector graphics with layers, hotspots, polylines, Bezier curves, arcs, ellipses, and hatch patterns
• Batch conversion of graphic files
• Snapping objects to grid, points, or segments
• Support for property bundles (line, fill, text, marker styles)
• Object manipulation: select, move, rotate, flip, slice, and remove fragments
• Callouts and hotspots integration
• Parametric gallery objects for adding tables
• 2D magnifier tool for zoomed-in views
• Quick preview mode with uniform line thickness

Capabilities

• Editing object properties in compliance with WebCGM 2.1
• Combining raster and vector image fragments
• Defining and exchanging styles across systems
• Scaling and converting all object types
• Adding and editing layers, points, and segments
• Filtering objects by type for multi-selection
• Arithmetic expression evaluation in text fields
• Saving and replacing raster images

Benefits

• Streamlined editing of technical illustrations and legacy graphics
• Enhanced interoperability with industry-standard formats
• Improved productivity through batch processing and automation
• Flexible styling and property management for consistent visual output
• Integration with Cortona3D ecosystem for seamless workflow
• Customizable and scalable for enterprise use
