Overview

CADWorx® Plant Professional is a comprehensive software solution designed to streamline the creation of intelligent 3D plant models. It offers a complete suite of tools for efficient plant design, catering to both greenfield and brownfield projects. By leveraging DWG-based deliverables, CADWorx ensures seamless integration with existing workflows, enhancing productivity and accuracy throughout the design process.

Features and Capabilities

• Intelligent 3D Piping Design: Facilitates the creation of detailed 3D piping models, ensuring precision and adherence to design specifications.
• Specification-Driven Design: Enables the use of predefined specifications to automate the design process, reducing manual input and minimizing errors.
• Efficient Specification Management: Streamlines the management of design specifications, allowing for easy updates and modifications.
• Dynamic Pipe Supports: Provides tools for the design and placement of pipe supports, hangers, and brackets, ensuring structural integrity and compliance with standards.
• Detailed Bill of Materials (BOM): Generates comprehensive BOMs directly from the 3D model, enhancing accuracy and facilitating procurement processes.
• Equipment Library Administration: Offers a centralized library for equipment components, promoting consistency and efficiency in design.
• Ducting and Cable Trays: Includes features for designing and modeling ducting systems and cable trays, supporting comprehensive plant design.
• Collision Checking: Identifies and resolves clashes within the 3D model, reducing the risk of design conflicts and costly rework.
• Isogen® Isometrics: Integrates with Isogen® to produce automated isometric drawings, streamlining documentation and ensuring consistency.
• Live Database Links: Maintains real-time connections to external databases, ensuring that design data is current and accurate.
• Intelligent Process Diagrams (P&IDs): Supports the creation of intelligent P&IDs, enhancing the integration between process design and 3D modeling.
• Model/P&ID Synchronization: Ensures consistency between the 3D model and P&IDs, facilitating accurate design and documentation.
• Links to Stress Analysis: Provides integration with stress analysis tools, allowing for comprehensive evaluation of piping systems.
• As-Builts from Point Clouds: Enables the creation of as-built models from point cloud data, supporting brownfield projects and facility maintenance.
